416 Backhoe Loader

Product description
Engine
  • Net Power - SAE J1349 - 86HP
  • Displacement - 220in³
  • Net Power Rating at 2,200 rpm - SAE J1349 - 86HP
  • Net Power Rating at 2,200 rpm - ISO 9249 - 85HP
  • Ratings at 2,200 rpm - Gross Power SAE J1995 - 96HP
  • Power Rating Conditions - No De-Rating Required Up To - 10000ft
  • Engine Model - C3.6 70 kW (96 hp) Electronic Turbo Intercooled
  • Emissions - Engine meets Tier 4 Final/Stage V emission standards.
  • Net Torque Rise - 1,400 rpm - SAE J1349 - 43%
  • Ratings at 2,200 rpm - Gross Power ISO 14396 - 94HP
  • Net Torque Rise - 1,400 rpm - SAE J1349 - 292ft-lb
  • Net Peak Power Rating @ 2,200 rpm - SAE J1349 - 86HP
  • Dimensions - Bore - 3.86in
  • Net Peak Power Rating @ 2,200 rpm - ISO 9249 - 85HP
  • Dimensions - Stroke - 4.72in
Backhoe
  • Dig Depth - Standard - 14ft
Weights
  • Operating Weight - Maximum - 24251lb
  • Cab - ROPS/FOPS - 306lb
  • Air Conditioning - 99lb
  • Operating Weight - Estimated* - 16532lb
  • Auto-Shift Transmission - 269lb
  • MP Bucket (0.96 m3/1.25 yd3) - Without Fold-Over Forks - 1642lb
  • Ride Control - 33lb
  • Note - *Machine configuration: standard stick hoe, OROPS canopy, 4WD standard shift transmission, 0.96 m³ (1.25 yd³) GP (General Purpose) loader bucket, 610 mm (24 in) standard duty hoe bucket, front 340/80-18 and rear 500/70-24 tires, 240 kg (530 lb) counterwei
  • Operating Weight - Maximum - ROPS Capacity - 24251lb
  • MP Bucket (0.96 m3/1.25 yd3) - With Fold-Over Forks - 2017lb
  • Counterweights, base - Maximum - 1014lb
  • Counterweights, base - 256lb
  • Loader QC - 540lb
  • Counterweights, base - Stackable, one - 529lb
  • Extendible Stick (excludes ft. counterweight) - 613lb
  • All-Wheel Drive - STD (N/A)
Hydraulic System
  • Pump Type - Variable-flow, Axial Piston
  • Type - Closed Center
  • System Pressure - Loader - 3336psi
  • System Pressure - Backhoe - 3336psi
  • Pump Capacity at 2,200 rpm - 34.9gal/min
Transmission
  • Note - Travel speeds of backhoe loader at full throttle, when equipped with 500/70-24 rear tires.
  • Power-Shift Transmission - Optional - Reverse - 3rd - 17mile/h
  • Power-Shift Transmission - Optional - Forward -1st - 3.7mile/h
  • Power-Shift Transmission - Optional - Forward - 2nd - 5.8mile/h
  • Power-Shift Transmission - Optional - Reverse - 1st - 3.7mile/h
  • Power-Shift Transmission - Optional - Reverse - 2nd - 7.6mile/h
  • Power-Shift Transmission - Optional - Forward - 4th - 25mile/h
  • Power-Shift Transmission - Optional - Forward - 3rd - 12mile/h
  • Power Shuttle Transmission - Standard - Forward - 3rd - 13mile/h
  • Power Shuttle Transmission - Standard - Forward - 2nd - 5.7mile/h
  • Power Shuttle Transmission - Standard - Forward - 1st - 3.4mile/h
  • Power Shuttle Transmission - Standard - Reverse - 4th - 23mile/h
  • Power Shuttle Transmission - Standard - Reverse - 1st - 3.4mile/h
  • Power Shuttle Transmission - Standard - Reverse - 3rd - 13mile/h
  • Power Shuttle Transmission - Standard - Reverse - 2nd - 5.7mile/h
  • Power Shuttle Transmission - Standard - Forward - 4th - 23mile/h
Axle Ratings
  • Rear Axle - Dynamic - 22046lb
  • Rear Axle - Static - 58422lb
  • Front Axle, AWD - Dynamic - 19841lb
  • Front Axle, AWD - Static - 51808lb
Steering
  • Turning Circle - (inner wheel not braked) - Outside Front Wheels - 26.92ft
  • Power Steering - Hydrostatic
  • Stroke - 4.2in
  • Bore - 2.6in
  • Turning Circle - (inner wheel not braked) - Outside Widest Loader Bucket - 35.25ft
  • Type - Front Wheel Steering
  • Axle Oscillation - 11°
  • Rod Diameter - 1.6in
  • Cylinder - One Double-Acting
Service Refill Capacities
  • Hydraulic System - 25.1gal (US)
  • Engine Oil - With Filter - 2.4gal (US)
  • Hydraulic Tank - 11.1gal (US)
  • Diesel Exhaust Fluid (DEF) - 5gal (US)
  • Cooling System with Air Conditioning - 4.8gal (US)
  • Rear Axle - 4.2gal (US)
  • Fuel Tank - 42.3gal (US)
  • Rear Axle - Planetaries - 0.4gal (US)
  • Transmission - Power Shuttle - AWD - 4.8gal (US)
  • Transmission - Power Shift - AWD - 5gal (US)
  • Front Axle (AWD) - 2.9gal (US)
  • Front Axle (AWD) - Planetaries - 0.2gal (US)
Standard Equipment:
  • Standard Equipment
    • Air cleaner
    • Alarm, back-up
    • Audible system fault alarm
    • Backhoe controls, mechanical two lever
    • Battery, maintenance-free, 850 CCA
    • Battery disconnect switch
    • Boom transport lock
    • Brace, lift cylinder
    • Brake, parking, mechanical
    • Brakes, hydraulically boosted, oil disc, dual pedals, interlocking
    • Bucket level indicator
    • Canopy, ROPS/FOPS
    • Coat restraint
    • Coolant/antifreeze, extended life
    • Counterweight, bumper
    • Dome light (cab only)
    • Diagnostic port for engine
    • Differential lock, loader joystick
    • Drink holders, two
    • Engine, Cat C3.6 (Direct Injection Turbocharged), meets Tier 4 Final/Stage V emission standards, Selective Catalytic Reduction, Diesel Oxidation Catalyst (DOC)
    • Engine enclosure, sound suppression, removable side panels
    • Face seals, O-ring
    • Fan, suction and guard
    • Fast reversing shuttle, all gears
    • Fenders, rear
    • Filters, spin-on: fuel, engine oil, transmission oil, water separator
    • Filters, bowl and cartridge: hydraulic fluid
    • Flashing hazards/signal lights
    • Floor mat
    • Four wheel drive
    • Four wheel drive shaft guard
    • Fuel tank, fully enclosed
    • Fully hinged front grill for cooling package cleaning access
    • Gauge cluster: coolant temperature, fuel level, torque converter temperature, DEF level
    • Ground level fuel fill and DEF fill
    • Halogen lights, working (2 front, 2 rear)
    • High ambient cooling package
    • Hood lock, inside cab
    • Hydraulic hose, XT
    • Hydraulic oil cooler
    • Hydraulic oil level sight gauge
    • Hydraulic valves, loader 2 function
    • Hydraulic valves, backhoe 4 function
    • Hydraulics, load sensing with variable displacement piston pump
    • Indicator lights: wait to start, water in fuel, engine warning, warning lamp, emissions module malfunction, low battery/charging system warning, high hydraulic oil temperature: LCD warnings: engine oil pressure, machine locked, service due, air filter blocked, high coolant temperature, auto idle shutdown, high torque converter temperature, hydraulic filter bypass
    • Instrument panel lights
    • Key start/stop system
    • LCD operator display with soft key controls: engine speed, hour meter, gear/direction, battery voltage, hydraulic oil temperature, torque converter temperature, coolant temperature, trip totals (fuel and hours), lifetime totals (fuel and hours), operator settings (units, brightness, programmable hoe auxiliary flow), service mode diagnostics, maintenance intervals, ECM/system info
    • Loader, self-leveling, return-to-dig and transmission disconnect switch
    • Loader, single tilt
    • Mechanical two lever controls
    • Mirror, interior, rearview
    • Open circuit breather
    • Power receptacle, 5 volt USB, 1 internal
    • Power receptacle, 12 volt, 2 internal, 1 external
    • Power steering, hydrostatic
    • Product Link, cellular, network manager
    • Product Link, satellite, network manager
    • Seat belt, retractable, 51 mm (2 in)
    • Socket, two roof
    • Stabilizer shoes, street
    • Steering column, tilting
    • Steering knob
    • Seat, air suspension, vinyl cover, with armrest
    • Starting system, glow plugs
    • Storage compartment, lockable
    • Storage tray
    • Stop and tail lights
    • Swing transport lock
    • Tilt steering column
    • Tires
    • Toolbox, external, lockable
    • Torque converter
    • Throttle, hand and foot, electronic
    • Transmission, four speed, manual, syncromesh
    • Transmission neutralizer switch
    • Transport tie-downs
    • Vandalism locks, four
    • Warning horn, electric
Optional Equipment:
  • Optional Equipment
    • Auxiliary hydraulics, rear, adjustable flow
    • Battery, additional, 850 CCA
    • Brake, parking, Spring Applied Hydraulically Release (SAHR)
    • Cab, standard
    • Cold weather fuel (–30° C/–22° F)
    • Cold weather package, including additional battery, engine block heater, radiator antifreeze (–50° C/–58° F), cold weather fuel (–30° C/–22° F) and mounting for an ether bottle
    • Counterweights, 115 kg (255 lb), 240 kg (530 lb) or 460 kg (1,015 lb)
    • Fenders, front with integral steps
    • Guard, boom protection plate
    • Guard, stabilizer, rock
    • Hydraulic valves, loader (3rd valve for MP or Quick Coupler)
    • Hydraulic valves, backhoe (5th and 6th function)
    • Hydraulic lines, combined function auxiliary
    • Joystick controls: pilot operated, excavator style with pattern changer
    • LED lights, working (2 front, 2 rear)
    • Pattern changer, in cab
    • Quick Coupler, hydraulic, dual lock
    • Quick Coupler, manual, dual lock
    • Quick Coupler, manual, pin lock
    • Radio and CD player, Bluetooth®
    • Ride Control
    • Rotating beacon, magnetic mount
    • Seat, air suspension, fabric with armrest
    • Seat belt, retractable, 75 mm (3 in)
    • Security system, Bluetooth
    • Security System, operator display
    • Side mirrors, cab, external
    • Single Tilt Loader Coupler, Integrated Tool Carrier (IT) Interface
    • Stabilizer pads, grouser type
    • Stabilizer pads, reversible
    • Stick, extendible
    • Transmission, 4 speed, powershift
    • Vandalism protection, gauge cover
    • Work Tool Attachments such as buckets, forks, material handling arms, augers, hammers, brooms, cold planers and vibratory plate compactors. See your Cat dealer for more information.
