Asphalt Pavers

SE60 V Screed

Product description

The SE60 V Vibratory Screed is equipped with rear-mounted extenders and fast heating screed plates, making it a perfect fit for parking areas, business developments, and other applications that require variable width paving. The low profile design enables good visibility for efficient operation. It has a paving range of 3.0 m to 7.65 m (9′ 10″ – 25′).

Weights
  • Standard Weight - 7495lb
Operating Specifications
  • Standard Paving Range - 3.0 - 6.0 m (9' 10" - 19' 6"')
  • Maximum Paving Width - 25ft
  • Maximum Paving Depth - 12in
  • Extender Height Range - -20 mm to +50 mm
  • Crown Range - -4% to +10%
  • Vibratory Speed Range - 0 - 3000 rpm
  • Extender Slope Range - -3% to +10%
  • Heating Time - Maximum Width - 25 minutes
  • Heating Time - Standard Width - 15 minutes
Dimensions
  • Transport Width - Endgates Folded - 9.85in
  • Transport Length - Tractor and Screed - 22.6ft
  • Screed Plate Width - Front to Back - 16in
  • Length - Front to Back, Endgates Attached - 94in
  • Length - Front to Back, Endgates Removed - 68in
